Product overview


1	Display panel see Displays on the bodypack transmitter display panel
2	Operation and battery indicator, red LED illuminated = ON, see Switching the bodypack transmitter on and off flashing = LOW BATTERY, see Inserting and removing the batteries/rechargeable batteries
3	Audio overload indicator, yellow LED illuminated = AF PEAK (overload), see Sensitivity menu item
4	UP button see Buttons for navigating the menu
5	SET button see Buttons for navigating the menu
6	DOWN button see Buttons for navigating the menu
7	ON/OFF button with ESC function in the operating menu Switch the transmitter on or off, see Switching the bodypack transmitter on and off Escape function in the menu, see Buttons for navigating the menu
8	Infra-red interface see Ew 100 G4 synchronizing
9	MUTE switch Deactivate and activate audio signal, see Muting the bodypack transmitter (AF mute) Deactivate and activate RF signal, see Deactivating the RF signal (RF mute)
